X-MW ALH CL 3/8’’ Wire hanger system
New product
Ultimate
Item #r13332430
Wire hanger system for electrical and mechanical trapeze and rectangular HVAC applications, installed using powder-actuated fastening tools
- Material: Carbon steel
- For use with (tools): DX 351, DX 460, DX 5, DX 6
- Base materials: Concrete (soft), Concrete (tough), Concrete (pre-cast), Concrete (normal weight over metal deck), Steel
Share
Features & Applications
Features & Applications
Features
- Shorter installation time – wire suspension kits give you a much faster alternative to threaded rod
- Easier to adjust – self-closing wire lock can be adjusted tool-free, making levelling, retrofitting and long drop lengths much simpler
- Aesthetic – wire rope suspension is a discreet installation method for exposed building services and open soffits
- Compatible with strut channels and MVA ventilation hardware – you can get solutions for virtually every MEP installation from one supplier
- Can be fastened while standing on the floor using the DX pole tool
Applications
- Suspending struts carrying HVAC fixtures, including spiral and rectangular ductwork to the concrete base material
- Suspending rectangular HVAC from the ceiling using MVA replacing the strut
- Suspending struts carrying electrical metal tubes, cable trays, cable baskets to the concrete base material
- Suspending lighting from ceiling
- Suitable for use in dry, indoor environments only
